This adjustable glass connector is clamped onto the upper glass edge of the fixed glass side panel and forms the lateral end of the reinforcement bar. Suitable for the Round 19 reinforcement bar.
Glass connector Round 19, end piece
Please to see prices.
Description
Your Advantages
- Stepless angle adjustment
- No glass processing required
Technical details
Adjustable
Yes
Diameter
30 mm
Glass processing required
No
Glass thickness TSG
8 - 10 mm
Height
58 mm
Material
Brass
Package contents
1 Piece
Shape
Round
Surface
Brushed
