Bilbao Premium angle connector 90° glass-wall for connecting a fixed glass side panel to a wall. Only simple glass holes in the glass panes are required.
About the product series Bilbao Premium:
The Bilbao Premium shower door hinge range combines modern, angular design with practical technical details, and all at an excellent price-performance ratio. The fittings are made of brass and are suitable for glass thicknesses of 8 mm, 10 mm and 12 mm. The zero position is adjustable for all hinges. The automatic return zone of ±15° to the zero position ensures convenient closing of the shower door. Outside this zone, the hinges hold any position.
Show allShow less
Your Advantages
Only glass drilling required
Concealed screws
Technical details
Angle
90°
Colour
Stainless steel colour
Concealed wall fixings
Yes
Degree of gloss
Matt
Flush
No
Glass thickness TSG
8 - 12 mm
Material
Brass
Mounting type
Glass-Wall
Package contents
1 Piece
Product series
Bilbao Premium
Rise/fall function
No
Surface
Nickel-plated
Surface treatment
Brushed
Show allShow less
Downloads
pdf
Instructions
Maintenance and Care Instructions
Drawings
jpg
jpg
jpg
jpg
jpg
For more drawings please log in:
