The Arta FM glass-glass 135-180° flush-mounted rebate shower door hinge has a load-bearing capacity of 40 kg. Doors up to 1 x 2 m can be realised. The hinge has a lifting and lowering function and can be used for 180° folding glass screens or 135° corner showers, for example.
Arta FM shower door fittings are the elegant solution for glass shower doors. The hinges are designed as single-action door hinges and allow the sealing profiles to be guided through the hinge. They have a flush-fitting, adjustable glass fixing that makes it easy to clean the glass. No disruptive screw fittings are visible on the classic, angular design. The zero position can be adjusted using a screw located on the underside of the hinge. The raising/lowering function with 5 mm lifting height enables the shower door to close independently. Due to the lowering of the door when closing, a better seal can be achieved due to increased sealing pressure. The shower door hinge is ideal for barrier-free, level-access bathrooms.
About the product series Arta:
The Arta series impresses with its clear design and many features, such as the integrated raise/lower mechanism and the infinitely variable zero position adjustment. The extensive product range consists of many variants and is therefore suitable for a wide range of installations. Robust materials inside the hinge guarantee a long service life.
