The Madrid shower door hinge has a load capacity of 45 kg. Doors up to a maximum size of 1 x 2.25 m can be realised. The 90° glass-wall mounting is designed for right-angled corner showers and recess showers.
All screw fittings on the strap are concealed so that nothing detracts from the high-quality look. The design is classically angular and therefore timeless. The sealing profiles can be guided through the hinge. No glass cut-outs are required for installation, only glass drill holes.
About the product series Madrid:
Madrid shower door fittings are an elegant solution for glass shower doors. The portfolio consists of numerous variants and is therefore suitable for almost all types of installations. A true all-rounder. The hinges are designed as single-action door hinges and enable the sealing profiles to be guided through the hinge. The design is characterised by its straight lines and is very popular in modern bathrooms. No disruptive screw fittings are visible. The Madrid shower door hinge enhances any glass shower!
Application note:
Please note the modified technical specifications for use in saunas.
The product is designed for private saunas up to 100 °C.
Seals may only be installed at a maximum temperature of 60 °C.
Use in steam rooms or swimming pools is not permitted.
