The innovative Juna® shower door hinge
Sophisticated technology meets first-class design
The range of possibilities
Juna 180° glass wall – the perfect addition to the series
The new 180° shower door hinge completes the successful Juna series. The special feature of this version is that no wall holes are required inside the shower, which minimises the risk of moisture damage to the wall structure.
Technical details:
- Load capacity: 50 kg
- Door size: max. 1 × 2.25 m
- Glass thicknesses: 6, 8 and 10 mm
- Surfaces: polished chrome, stainless steel effect, black
- Concealed cover caps with utility model-protected plug-in technology
- Adjustable zero position
- Tested with 100,000 cycles
- Self-closing from approx. 20°
- Materials: stainless steel, brass
Juna 180° Connector
Juna connectors are available in two versions - flush or not flush with the wall. Flush connectors enable continuous, flush lines and are ideal for modern, minimalist shower designs. Non-aligned versions offer more scope for positioning, for example in the case of structural features or offsets. Both versions do not require visible wall drill holes in the interior - for a clean look and improved moisture protection.
Technical details:
- Glass thicknesses: 6, 8 and 10 mm
- Surfaces: Bright chrome-plated, stainless steel effect, black
- Cover caps with protected plug-in technology
- Materials: Brass
Supreme design
The high-quality appearance of the shower door hinge immediately catches attention. Minimum gap dimensions, no visible screws, even as far as the zero position adjustment is concerned, and a practically continuous sealing strip emphasize its classy look. Another comfortable feature is the above-average return angle of approx. 20° which closes the glass door automatically.
Perfect zero position
Thanks to the innovative clamping technology, no disturbing notches are produced on the hinge axis – for a precise adjustment of the zero position down to the millimetre. The clamping screws and the zero position fixing screw have uniform screw heads which can be conveniently tightened with just one tool. The centred mounting plate enables the optimum positioning of the cover cap. A stable plug connection guarantees its firm and precise fit.
- Adjustment down to the milimetre
- Innovative clamping technology
- 5 years guarantee
- Successfully tested with 100.000 door cycles
Efficient mounting with only one tool
The clamping screws and the zero position fixing screw have uniform TX30 screw heads which can be conveniently tightened using only one tool. The troublesome exchange of screwing tools while working is therefore a thing of the past. In addition, the elongated holes for the wall connection provide increased comfort when adjusting the hinge. Two-part clamping plates also enable deeper threaded holes in the fitting and thus ensure a safe grip. At the same time, the hinge is protected against deformations on the outside.
- Unifrom srew heads
- TX 30 screw heads
- Two-part clamping plate
- Hinge is protected against deformations
Precise fit of cover caps
The high quality design of Juna stands out thanks to its minimum gap dimensions. One of the prerequisites is the precise fit of the cover caps. For this purpose, Bohle has developed an innovative 4-point fixing mechanism which fixes the caps exactly in place. This is made possible by four small centring pins and the tailor-made seating in the hinge. In addition, water resistant rubber rings provide additional hold. In this way, the cover caps are maintained in their exact position for years, without slipping.
